Design and fabrication of different shapes of Microstrip Patch Antenna

Name: Design and fabrication of different shapes of Microstrip Patch Antenna
Brand: LAP LAMBERT Academic Publishing
Availability: OutOfStock
Rating: 5 (1 reviews)

By Ezzulddin, Saman Khabbat

0 - Default Title

Description

This work is proposed to design and fabricate microstrip patch antennas MPAs operatiThis work is proposed to design and fabricate microstrip patch antennas MPAs operating at (28) GHz that provides adequate radiation performance reliable for (5G) application which proceeds through the following steps.In the first senario, the rectangular, circular and triangular MPAs are designed to operate at (28) GHz by implementing Computer Simulation Technology (CST) software. The MPAs are built on the dielectric substrate material named Rogers (RT5880) of relative permittivity(¿_r=2.2). The simulation results reveal that a smaller antenna patch area of the order of (7.86) mm2 is achieved with TMPA, while the best reliable value of (S11) and voltage standing wave ratio (VSWR) is obtained with CMPA. while, the computed results of the fundamental antenna parameters such as gain, directivity, bandwidth and efficiency are found to be obtained with RMSA, which are (6.63) dB, (7.09) dB, (0.967) GHz and (90%), respectively.

Product details

Binding:: Paperback
Number of Pages:: 204
Release Date:: 2025-10-27
Publication Date:: 2025-10-27
Publisher:: LAP LAMBERT Academic Publishing
Languages:: Original: English
ISBN10:: 6209146546
ISBN13:: 9786209146541
Weight:: 322 g
Height:: 15 cm
Width:: 22 cm
Thickness:: 1.3 cm

Buy on Amazon

Currently sold out
